Side Draft Liquid Painting Booth

Name: Side Draft Liquid Painting Booth
Brand: MASTERFIELD SYSTEMS
Price: 325000 INR
Availability: InStock

Price 325000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Side Draft Liquid Painting Booth Specification

Usage
Industrial

Type
Paint Booth

Surface
Plating

Technology
Wet and Dry Filtration

Attributes
High Efficiency, User-friendly Operation, Durable Construction

Product Type
Side Draft Liquid Painting Booth

Power Source
Electric

Power Consumption
As per design (commonly 2-7.5 HP motor)

Voltage
220/415 V

Portable
No

Protection System
Explosion-proof electricals and proper ventilation

Material
Mild Steel

Booth Dimensions
Customizable as per requirement

Control Panel
Automatic/Manual options available

Suitable For
Automotive, Heavy Equipment, General Industrial Painting

Exhaust System
Heavy-duty centrifugal fan

Lighting
Fluorescent, explosion-proof

Air Flow Direction
Side Draft

Noise Level
Less than 75 dB

Filtration Stage
Multi-stage (Pre-filter, Paint Arrestor, Final Filter)

Installation Type
Floor Mounted

Air Velocity
0.3 - 0.5 m/s (customizable)

Side Draft Liquid Painting Booth Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
7 Units Per Month

Delivery Time
20 Days

About Side Draft Liquid Painting Booth

We are one of the market leading organizations engaged in manufacturing and supplying Side Draft Liquid Painting Booth. These booths are suitable for providing excellent coating on automobile, textile, home appliances, stabilizers, aluminum extrusions, elevators, CNC machines, radiators and furniture. Owing to their wider application area, these booths are highly demanded around the globe. We fabricated these booths as per the international norms and standards so as to make them efficient and cost-effective in nature. Offered Side Draft Liquid Painting Booth can also be customized as per the needs and demands of our valued patrons.

Efficient Side Draft Airflow

The booth's side draft airflow ensures contaminant-free painting by drawing air horizontally across the work zone. This design minimizes paint overspray, enhances finish quality, and protects operators. Air velocity stays within 0.3 - 0.5 m/s to deliver optimal performance for a wide range of industrial applications, and can be customized to your specific requirements.

Advanced Multi-Stage Filtration

Outfitted with a pre-filter, paint arrestor, and final filter, this booth combines wet and dry filtration methods to ensure a clean working environment. The multi-stage system effectively captures particulates and vapors, supporting compliance with safety and environmental standards while reducing maintenance demands on exhaust systems.

Customizable, Durable, and Safe

Constructed from mild steel, this booth can be customized in size to fit varied operational needs. Explosion-proof lighting and electricals, together with reliable ventilation, make it suitable for handling hazardous materials safely. The control panel supports both manual and automatic operation for user flexibility, while the robust build ensures long-lasting service.

FAQ's of Side Draft Liquid Painting Booth:

Q: How does the side draft airflow system benefit my painting process?

A: The side draft airflow system provides uniform air movement horizontally across the booth, which reduces the risk of airborne contaminants and ensures a high-quality paint finish. This setup effectively sweeps overspray and particulates away from the painted item, resulting in improved coating consistency and operator safety.

Q: What filtration stages are used in this painting booth, and why?

A: This booth employs a multi-stage filtration system including a pre-filter, paint arrestor, and final filter. These stages work together to capture coarse and fine particulates, as well as paint vapors, ensuring both environmental compliance and reduced maintenance for the booth's exhaust system.

Q: When and where is a side draft liquid painting booth typically installed?

A: Side draft booths are ideal for automotive workshops, heavy equipment manufacturing, and general industrial facilities. Installation is floor-mounted, making it suitable for new builds or retrofitting into existing production lines. The booth's custom dimensions allow for flexible placement according to facility layout.

Q: What is the process for painting inside this booth?

A: The painting process involves positioning the workpiece inside the booth, activating the chosen control mode (automatic or manual), and utilizing explosion-proof lighting for visibility. As spraying begins, the side draft airflow and filtration stages manage overspray and contaminants, while the exhaust system safely ventilates fumes.

Q: How safe is this paint booth for handling hazardous materials?

A: Safety is a priority, with explosion-proof electrical components, proper ventilation, and high-efficiency filtration systems in place to safely handle volatile solvents and paints. The design and material construction comply with industrial safety standards, offering enhanced operator protection.

Q: What customization options are available for booth dimensions and airflow?

A: Booth sizing and airflow velocities are fully customizable to suit your operational requirements. The air velocity, typically 0.3 - 0.5 m/s, can be adjusted, and booth dimensions are tailored according to your workspace and application needs.
